| ΝΗΜΑ ΔΙΑΜΕΤΡΟΣ &ΚΑΤΑΛΑΜΒΑΝΟΥΝ (mm) |
ΒΑΡΟΣ καθε (κιλό) |
DIMENSIONS (mm) | ||||||||
| A | D |
E ΚΛΕΙΣΤΟ |
F |
J ΑΝΟΙΞΕ |
K ΚΛΕΙΣΤΟ |
M ΑΝΟΙΞΕ |
N ΚΛΕΙΣΤΟ |
ΒΒ | ||
| 6,35x102 | 0.15 | 6.35 | 11.2 | 42.3 | 32.3 | 249 | 187 | 310 | 208 | 103 |
| 7,94x114 | 0.24 | 7.94 | 12.7 | 50.7 | 38.1 | 294 | 218 | 358 | 243 | 116 |
| 9,53x152 | 0.38 | 9.53 | 14.2 | 57.8 | 44.7 | 387 | 270 | 453 | 301 | 155 |
| 12,7x152 | 0.85 | 12.7 | 16.5 | 89.7 | 57.9 | 457 | 335 | 527 | 375 | 153 |
| 12,7x305 | 1.26 | 12.7 | 16.5 | 89.2 | 57.9 | 769 | 495 | 839 | 535 | 314 |
| 15,9x305 | 1.46 | 15.9 | 22.9 | 108 | 71.4 | 495 | 368 | 572 | 419 | 153 |
| 15,9x305 | 2.08 | 15.9 | 22.9 | 107 | 71.4 | 809 | 529 | 885 | 580 | 315 |
| 19,1x152 | 1.91 | 19.1 | 24.9 | 129 | 84.6 | 538 | 406 | 620 | 467 | 156 |
| 19,1x305 | 3.14 | 19.1 | 24.9 | 128 | 84.6 | 853 | 568 | 935 | 630 | 320 |
| 19,1x457 | 3.92 | 19.1 | 24.9 | 129 | 84.6 | 1158 | 721 | 1240 | 782 | 471 |
| 22,2x305 | 4.47 | 22.2 | 28.7 | 148 | 96 | 886 | 597 | 972 | 667 | 309 |
| 25,4x305 | 6.7 | 25.4 | 31.8 | 167 | 108 | 929 | 637 | 1019 | 714 | 309 |
